Simple Operation Small Hard Candy Making Machine High Production Efficiency

Place of Origin Jiangsu, China (Mainland)
Brand Name Haitel
Certification CE ISO9001
Model Number HTL-T83-3-1
Minimum Order Quantity 1 Set
Price Negotiable
Packaging Details Wooden case packing according to your demand
Delivery Time 60day(s) after payment received
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 15 Piece/Pieces per Month
Product Details
Voltage 380V Power(W) 14000W
Weight 1000 Kg Dimension(L*W*H) 6690*700*1400 Mm
Function Machines For Making And Packing Hard Candy Production Capacity 150 Kg/h
Application CANDY Warranty 1 Year
High Light

candy pillow pack machine


candy production machine

Leave a Message
Product Description





Automatic Small Hard Candy Making Machines Production Line



Production Line Introduction:




The SWM-HCD series Hard Candy Depositing Line is the advanced confectionery machine for making various kinds of hard candies, such as clear hard candies, 2-color, striped hard candies, layered hard candies, center-filled products, etc. The line offers high output, good quality of products, automatic operation and high levels of production efficiency.
The line is continuously depositing syrup from Microfilm Cooker at final moisture into metal moulds.
This makes candies have smooth surface finish and good taste.

There are two types of hard candy depositing machines: mechanical depositing machines and servo driven with motion controller or PLC depositing machines for making hard candies with center filling.

The capacity of the mechanical depositing machines is from 300kgs to 450kgs and the servo driven depositing machines is from 300kgs to 600kgs.
Main techinical :

Production capacity
Steam consumption
Steam pressure
Compressed air consumption
Compressed air pressure
Water consumption
Sizes of machine
Weight of machine



Cooling sifter

Voltage 380V
Power 0.75KW
Weight 160kg
Dimension(L*W*H) 3000*500*400mm





  N0 Name
 1 Steam Sugar Cooking Pot
 2 Syrup pump
 3 Storage Tank
 4 Pipes, Valves
 5 HTL-250 Vacuum Sugar Pot
 6 Cooling device
 7 Thermo roller

Bracing machine

 9 HTL-83-3-1 Forming machine
 10 Cooling sifter




1. Steam Sugar Cooking Pot


Mixer power 1.1kw
Maximum capacity 200L
Weight 100kg
Mixing rotate speed 30rpm/min
Dimension(mm) φ1000*1200mm




2. Syrup pump


Rate of flow 200-500L/h
Max pressure 20bar
Stroke frequency 58/78/116time/s


Voltage 380V
Stroke length 25mm




3. Storage Tank


Maximum capacity 200L
Weight 100Kg
Dimension φ900*1200mm



4. HTL-250 Vacuum Sugar Pot


Capacity 400kg/h
Heating area 2.45m2
Steam pressure Min.0.65MPa
Steam consumption 110kg/h
Temp. of the syrup before cooking 105-115℃
Temp. of the syrup after cooking 120-130℃
Power 0.75KW
Dimension(L*W*H) 1600*1400*2000mm
Weight 680kg


5. Cooling device


Dimension (L*W*H): 2000×1800×800 mm

Made of stainless steel

Use water for cooling


6. Thermo roller


Voltage 380V
Power 3kw
Weight 500kg
Dimension(L*W*H) 2200*700*1400mm



8. Bracing machine


Voltage 380V
Power 2KW
Weight 500kg
Dimension(L*W*H) 1200*700*1300mm


9. HTL-83-3-1 Forming machine

Our Services


confirm machine type: Negotiate with clients to seclect the correct machine according to customers‘ requirment.
Quote and Sign firm contract: After confirm with customers with all details, such as payment terms,model, delivery time,send official quotation to clients.


1,  When equipments arrive in clients factory,send engineers there for installation and ensure customers know how to operate the machine.
2,  In order to improve our products,we keep in close contact with customers to know their feedbacks and suggestions.
3.  From the date of the Buyer receipt the machines, free warrant for 12 months.
