Vertical Automatic Mini Donut Machine With Scale 304 Stainlesss Steel

  • Vertical Automatic Mini Donut Machine With Scale 304 Stainlesss Steel
  • Vertical Automatic Mini Donut Machine With Scale 304 Stainlesss Steel
Place of Origin Jiangsu, China (Mainland)
Brand Name Haitel
Certification CE ISO9001
Model Number HTL-V620
Minimum Order Quantity 1 piece
Price Negotiable
Packaging Details Wooden case packing according to your demand
Delivery Time Shipped in 45 work days after payment
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 15 Piece/Pieces per Month
Product Details
Warranty 1 Year Application Food
Packaging Material Metal Condition New
Driven Type Electric Place Of Origin Jiangsu, China (Mainland)
High Light

candy bar packaging machine

,

candy pillow pack machine
Leave a Message
Product Description



Vertical automatic mini donut machine



Vertical automatic mini donut machine with scale , 304 stainlesss steel



Product Description

1. Film drawing down system controlled by servo motor.

2. Automatic film rectifying deviation function.

3. Various alarm system to reduce waste.

4. It can complete feeding, measuring, filling, sealing, date printing, charging (exhausting), counting, finished product delivery when it equips with feeding and measuring equipment.

5. The way of bag making: The machine can make pillow-type bag and standing-bevel bag, punch bag or according to customer’s requirements.

Application

It is suitable for packing of several of granule, powder, such as sugar, salt, coffee, etc.



Main technical

Model HTL-D420
Packing speed About 30-60 bags/min. It is according to quality of wrapping film and materials.
Accuracy ≤1.5%
Bag size (L) 80-300 mm; (W)80-180 mm
Maximum film width 420 mm
Filling range 50-1000 g
Film thickness 0.04-0.09 mm
Packing material Thermal composite materials, such as BOPP/CPP, PET/AL/PE
Air consumption 0.8 MPa, 0.4 m³/min
Total power 5 KW
Voltage (V) Four wires, three phases, 380V, 50Hz.
Air compressor Not less than 1 CBM
Total height 2528 mm
Gross weight 900 kg





Touch-sensitive screen WEINVIEW Taiwan
Programmer controlled system SIEMENS Germany
Servo motor PANASONIC Japan
Servo driver PANASONIC Japan
Cylinder SMC Japan
Cylinder SMC Japan
Electromagnetic valve JINGQI Taiwan
Intermediate relay Weidmuller Germany
Photoelectric eye BEDELI Taiwan
Powder ZHANGXIN China
Solid state relay XIANLI / OMRON
Thermometer control OMRON



Vertical Automatic Mini Donut Machine With Scale 304 Stainlesss Steel 0
