220V 4KW Multihead Weigher Pastry Packing Machine for Soft candy ， hard candy
| Place of Origin | Jiangsu, China (Mainland) |
|---|---|
| Brand Name | Haitel |
| Certification | ISO9001 |
| Model Number | HTL-V520 |
| Minimum Order Quantity | 1 Set |
| Price | Negotiable |
| Packaging Details | Wooden case packing according to your demand |
| Delivery Time | Shipped in 45 work days after payment |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 100 Piece/Pieces per Year |
Product Details
| Volumn Range | 3000Max | Bag Length(mm) | 80-400(L) |
|---|---|---|---|
| Bag Width(mm) | 80-250(W) | Power(KW) | 4 |
| Voltage | 220V | Max Width Of Roll Film(mm) | 520 |
| Packing Speed(bags/min) | 5-50 | Air Consumption(Mpa) | 0.65 |
| Gas Consumption | 0.4m3/min | Weight | 600kg |
| High Light | automatic bag packing machine,automatic blister packing machine |
||
Product Description
14 head weighing vertical packing machine
Application:
The bagging machine is widely used for packing of products in shape of granules, stripes, slices, such as candy, potato chips, jelly, and peanuts.
Characteristics:
1. Touch screen with stable transmitting PLC control to perform bag making, weighing, filling, sealing, code printing, and cutting automatically.
2. Independent compressed air control and electrical wire system control separately, low noise in running, stable performance.
3. Vacuum belt pulling system to feed film and make bags with no faults.
4. Double servo control system, precise positioning.
5. Easy to palce the rewind rolls onto the machine.
6. Set uo and adjust parameters on touch screen to change bag size.
7. Sealed structure design to prevent dust contamination.
8. Multi computerized weighing heads to deliver correct weight.
Specifications:
| Mode |
HTL-V520
|
| Bag length(mm) |
80-400(L)
|
| Bag width(mm) |
80-250(W)
|
| Max width of roll film(mm) |
520
|
| Packing speed(bags/min) |
5-50
|
| Volumn range |
3000Max
|
| Air consumption(Mpa) |
0.65
|
| Gas consumption(m3/min) |
0.4
|
| Power voltage |
220V
|
| Power(KW) |
4
|
| Dimension(L*W*H)mm |
1150*1795*1650
|
| Weight(kg) |
600
|
